Rubber Testing Instruments

The oven controller has Special T/P action to avoid overshooting of temperature. It has Stainless Steel Inside Chamber, Outer is Mild Steel neatly powder coated.

Complete with Hot air blower and Digital Temperature Indicator cum Controller. A separate control panel housing all indicators is provided on the right side of the main body allowing easy maintenance and accessibility Aesthetically designed for long life and comfortable usage. Two Stainless

Technical Specifications:

• Other sizes available on request
• Digital Programmable timer available as an optional accessory

This method covers the estimation of the resistance of vulcanized rubber to cracking when exposed to an atmosphere containing ozone. The rubber specimens are kept under a surface tensile strain, and the ozone content or partial pressure in the test chamber is maintained at a fixed value.

Providing precise and accurate ozone (O3) concentration environment for rubber and polymer test. Widely applied to (1) Accelerated ageing research (2) Quality control and assurance tests and (3) R& D laboratory formula experiments for cracking resistance. Wide ranges of ozone concentration (normal 20-250 pphm; or according to customer's request) can satisfy user's different requirements. The real ozone concentration is controlled and measured accurately by means of precise detecting system. Excellent system control: (1) Maintaining rapid resumption of O3 concentration during continuous circulation Economy and efficiency: (2) Full automatic test after simple settings.

The Ozone Test chamber enables a sample comparison; on specimen prepared from the test slabs or molded/ extruded rubber products; to determine resistance of the rubber to ozone concentration controlled at a predetermined level in the ranges 25-50/50-100/100-200 PPH/M at predetermined temperature.

Technical Specifications:

• Test Temp.: 40 oC- 60 o C at room temp. 20 o C to 25 oC.
• Test Space Volume: 125 liters. (500x500x500mm).
• Test Space Interior: SS 304
• Door: Full view door with lass .
• Interior Light: For sample examination.

Applicable Standards:
ASTMD 1149; D1171; D3395; ISO Standard 1431l/ll/Hl and IS 3400 Part 20. ISO 1431 & JIS K6259 standards.

Computer Based Tensile Testing Machine - Zeus Ultimo
Capacity : 250 Kgf; Least Count :100 gm
Type : Floor standing; C.R.E. Type.
Grip to Grip Separation : Minimum 25mm and Maximum 700mm. Two sets supplied with the machine.
Cross Head Speed : 50mm - 500mm / min. With Servo Motor Variable Speed.
Speed Control : Through Graphic user interface PC. Cross Head Travel Length : Overall travel length 800mm without Grips.
Load Sensor : Universal 'S' Type / Pancake Type.
Load Sensor Accuracy : +0.5% of the Load Cell capacity. Calibrated by NPL approved proving ring dynamometers.
Load Sensor Sensing : Auto - detect / sensing through advance electronics. Electronic Auto-Zero
Over Load /Travel Safety : Auto stop through software : 10% above load cell capacity/ Built in
Systems Controls : Advance Micro - controller systems

Capacity Available

It is based on the Constant Rate of Traverse (CRT) principle. The sample is held between two jaws; the upper one is a stationary jaw while the other end is made to move at a known fixed speed with the help of Motor, Gear Box and Lead Screw arrangement (100mm or 300mm per minute). The load exerted on the Stationary jaw is sensed by a sensor connected with load cell which directly indicates the load in Digital form in kg.

Technical Specifications:

• Other Ranges also available

All Stainless Steel, Flammability Tester with Stainless Steel Brushing device. This latest model has changed internal designs to undertake large number of Testing conveniently in a Short Time. The unit adheres to ASTM D-1230 & other International Standards. Used to determine the burning characteristics of Textiles under Controlled Conditions. Stainless Steel Test Cabinet with clear Observation Panel. The unit has DIGITAL Timer for automatic Timing of flame speed. Supplied with 5 Nos. Stainless Steel Specimen Holders, Clips for fixing the Specimen, Clips for Micro Switch Operation, Dead Weight, 2 Nos. Guages, empty Gas Cylinder, Gas Pipe with Stainless Steel Clamps along with Brushing Device. Complete unit with a CALIBRATION CERTIFICATE, Traceable to NPL, along with an Inspection and Conformance Certificate

It is a portable equipment equipped with an external sensor probe having a 45/0 degree colour measuring geometry. It uses the spectral analysis method to determine the colour of the sample

It has user friendly features to get the colour value ( R; G; B or H; S; L ); comparison of colour value is easy for two measurement materials.

This method covers the use of the oscilating disk curemeter for determining the vulcanization characteristics of vulcanizable rubber compounds. In this method, a specimen of compounded rubber is contained in a sealed test cavity under a positive pressure and maintained at an elevated temperature. A biconical disk is embedded in the test specimen and is oscillated about the shaft axis through a small are. This action exerts a shear strain on the test specimen and the force at maximum amplitude (torque) required to oscillate the disk is proportional to the stiffness (shear modulus) of the rubber. This torque is recorded autographically as a function of time.

The stiffness of the rubber specimen increases during vulcanization. A test is completed when the recorded torque either rises to an equilibrium or maximum value, or when a predetermined time has elapsed. The time required to obtain a curve is a function of the test temperature and the characteristics of the rubber compound.

Graphics including Elastic torque; Cure rate; and Upper/Lower dies temperatures. Data; such as ML; MH; TS; TC; CRI etc.; can be taken from each test. Cure curve provides the processing; vulcanizing; and vulcanized physical properties of rubber cross-linking reaction. Multiple control gates are available for controlling the specified data such as ML; MH; TS; and TC. Standard accessory - SPC (Statistical Process Control) software is used to analyze and draw the statistical control charts including X-RM; -R; histogram; and normal distribution for some specified data.

Applicable Standards:
ASTM Standards: ASTM D2048& ISO 6502 The equipment is built on a rigid metallic base plate and finished in Autumn Gray & Blue combination painting and bright chrome / zinc plating to give it a corrosion resistant finish. The Instrument comes complete with Instruction Manual ,Electrical Wiring Diagram & Calibration Certificate traceable to NABL approved Labs.
